19 Inch Open Frame Infrared Touch Monitor IP 65 Waterproof Touch Screen
Infrared Touch Monitor Main Features
- Infrared touch screen, accurate touch, fast response, 1- 40 points optional
- Support embedded,wall-mounted,rack-mounted,desktop,VESA support
- IP65 grade water-proof,dust-proof for front panel.
- Compatible with various industrial systems/application
- Aluminum alloy shell,good mechanical properties,better performance of heat dissipation
- CCC, ETL, FCC, CE, CB, RoHS certificate.
- Support system: XP, WIN7, WIN8, Linux
- Other sizes can be offered (7’’- 43’’)
Infrared Touch Monitor Specifications
| Model No. | KOT-0190U-IR3W |
| Series | OT |
| Display Type | 19＂Active Matrix TFT-LCD |
| Display Active Area | 14.8＂(377mm)×11.9＂(301mm) |
| Suggested Resolution | 1280×1024@60Hz |
| Support Colors | 16.7M |
| Brightness(Typ.) | Pure LCD Panel | 250cd/m2 |
| With SAW Glass | 225cd/m2 |
| Response Time(Typ.) | 16ms |
| Viewing Angle | Horizontal(left/right):(85°/85°) |
| (Typ.at CR＞10)) |
| | Vertical(up/down):(80°/80°) |
| Contrast Ratio(Typ.) | 1000:1 |
| Video Input | Analog RGB |
| Frequency(H/V) | 30～80KHz / 60～75Hz |
| Power Supply | Type: External brick |
| Input (line) voltage: 100-240 VAC, 50-60 Hz |
| Environment | Operation Temp: | 0～50°C |
| Storage Temp: | -20～60°C |
| Operation RH: | 20%～80% |
| Storage RH: | 10%～90% |
| MTBF | 50,000 Hours |
| LED Back light Life(Typ.) | 50,000 Hours |
| Weight(N.W/G.W) | N.W :5.85Kg (Single) |
| Power Consumption | 15W Max. |
| Standby power consumption | 0.95W |
| Mount Interface | 1)VESA 75mm and 100mm |
| 2)Mount bracket, horizontal or vertical(Standard mount brackets are supplied) |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset |
| Touch screen Type | Keetouch 19" IR Touch Mointor |
| Support System | WinXP,Win7,Win8,Linux |
| Touch System Interface | Having USB interface |
| Touch Response time | 16ms |
| Agency Approval | CCC,UL,FCC,CE,CB,RoHS |
| Regular Warranty | 1 year |
Infrared Touch Monitor Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.
2. Do you have stock?
Yes, we have a large quantity of stock for our regular model products.
3. What is your warranty period for the infrared touch monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Do you support customization?
Yes. We are the manufacturer of Industrial Touch Screen and Touch Monitor. And have professional R&D Team, could customized the touch monitor according to your requirement.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
6. How to ship to us from your factory?
Optional: Fedex/DHL/UPS/EMS, by air, by sea or to your China forwarder.
